How I Stopped a Silent Memory Leak in My iOS App

Memory Profiler SDK: https://github.com/egzonpllana/memory-profiler-ios

While reviewing one of my personal iOS apps over the weekend, I uncovered a memory issue that had gone unnoticed: a memory leak that was silently eating away at system resources. What started as a casual check turned into a deep dive into memory profiling, optimization techniques, and eventually… an open-source service others can now benefit from.

Let me take you through the journey of how I went from achieving 85% memory reduction on a common user interaction.

The Problem

While casually exploring the app, I noticed something off: the RAM footprint would jump 10–15MB with every tab switch. Ten minutes of typical usage and memory bloated from 196MB to over 300MB. No downward trend. Just continuous accumulation.

That’s a massive red flag for memory leaks - especially in production-grade apps where memory pressure can quickly become app-killer territory.

Here’s a breakdown of what I was seeing:

• 196MB baseline memory on cold launch
• +10–15MB per tab switch
• After 10 mins: ~310MB+ and growing

It wasn’t a single bug. It was a pattern. And I needed a systemic solution.

Diagnosis

After digging deeper with Instruments, I confirmed what I suspected:

• Views weren’t being deallocated.
• Combine subscriptions weren’t canceled.
• Timers weren’t invalidated.
• The SwiftUI .id() modifier was doing more harm than good.

It was death by a thousand cuts. My tools weren’t giving me what I needed in real time.

So I built one.

Solution: A Custom Memory Profiler for Swift Apps

I needed to observe memory usage during app lifecycle events - especially tab switches - without the latency of Instruments or Xcode debugging. So I created a real-time memory monitoring service using low-level system APIs.

Here’s what I implemented:

Real-Time Monitoring

I used mach_task_basic_info to access the app’s resident memory size and paired it with ProcessInfo.processInfo.physicalMemory for context.

Automatic Threshold Alerts

By default, the profiler sets a warning threshold at 70% of physical memory - a common best practice. It logs a warning if memory exceeds that.

Leak Pattern Detection

It is structured to track peak memory usage, record historical data, and prepare for advanced analysis.

Timer-Driven Sampling

Every 60 seconds, the profiler captures current stats and logs trends - lightweight enough for debug builds and safe for Swift Packages.

Key App Fixes Beyond the Profiler

The profiler helped me identify specific root causes in the UI:

1. View Recreation via .id()

SwiftUI’s .id modifier can force complete reinitialization. I was using it on tab switches, unintentionally keeping views alive.

Solution: Removed .id usage where not needed.

TabView(selection: $selectedTab) {
    HomeView()
        .id(UUID()) // This forces recreation on every render
        .tabItem { Text("Home") }
        .tag(0) // Tag is enough, no ID needed.
    SettingsView()
        .id(UUID()) // Same issue here
        .tabItem { Text("Settings") }
        .tag(1) // Tag is enough, no ID needed.
}

2. Asynchronous task lifecycle

Combine pipelines weren’t being torn down.

final class MyViewModel: ObservableObject {
    private var cancellables = Set<AnyCancellable>()
    private var task: Task<Void, Never>?
    private let apiClient: APIClientProtocol

    init(apiClient: APIClientProtocol) {
        self.apiClient = apiClient
    }
    func loadPosts() {
        // use task properly.
        task = Task { [weak self] in
            do {
                let posts: [PostDTO] = try await self?.apiClient.fetchPosts()
                //
            } catch {
                //
            }
        }
    }
}

final class PostsViewModel: ObservableObject {
    private let apiClient: APIClientProtocol
    private var loadTask: Task<Void, Never>?

    init(apiClient: APIClientProtocol) {
        self.apiClient = apiClient
    }
    deinit {
        loadTask?.cancel()
    }
    /// Loads posts asynchronously using the API client.
    /// - Note: Cancels any ongoing load operation before starting a new one.
    func loadPosts() {
        loadTask?.cancel()
        loadTask = Task { [weak self] in
            guard let self else { return }
            do {
                let posts: [PostDTO] = try await apiClient.fetchPosts()
                // Assign or process `posts` as needed
            } catch {
                // Handle error
            }
        }
    }
}

Manual task management: task handle stored and cancelled in deinit for proper lifecycle control.

3. Timer Leaks

Timers retained self.

Solution: Used [weak self] captures, and explicitly invalidate() timers on view disappear.

The problem? Timer strongly retained self, and since I didn’t invalidate it, the view model stayed in memory even after the view disappeared.

final class CountdownViewModel: ObservableObject {
    private var timer: Timer?
    @Published var secondsLeft: Int = 60

    func startTimer() {
        timer = Timer.scheduledTimer(withTimeInterval: 1.0, repeats: true) { _ in
            self.secondsLeft -= 1
        }
    }
}

The fix involved two parts: using [weak self] to avoid retain cycles, and explicitly invalidating the timer in deinit.

final class CountdownViewModel: ObservableObject {
    private var timer: Timer?
    @Published var secondsLeft: Int = 60

    func startTimer() {
        timer = Timer.scheduledTimer(withTimeInterval: 1.0, repeats: true) { [weak self] _ in
            self?.secondsLeft -= 1
        }
    }
    deinit {
        timer?.invalidate()
    }
}

The Results

Once I integrated the profiler and resolved the root causes, the improvements were immediate and measurable:

• Tab switching memory impact dropped from 10–15MB to just 1–2MB.
• Total memory usage after 10 minutes stabilized around 211MB, instead of ballooning past 310MB.
• Responsiveness issues completely disappeared - the app remained fluid even under stress.
• Leak patterns, previously triggered by multiple sources, were fully eliminated.

These optimizations not only made the app more stable but also gave me a repeatable system for catching regressions before they escalate. The app now maintains stable memory usage, and the profiler gives me confidence every new build won’t regress.

Why I Open-Sourced It

I didn’t build this for fun (though it was fun). I built it because I needed visibility into a system-level issue that was otherwise invisible until too late. And I figured other iOS devs might be dealing with the same problem - unknowingly shipping apps with slow-growing leaks.

So I open-sourced it.

You can find it here: https://github.com/egzonpllana/MemoryProfiler

Under the Hood

Here’s a peek at what the service gives you out of the box:

let profiler = MemoryProfilerService()
profiler.startMonitoring()
profiler.logMemoryUsage(context: "TabSwitch")

You can check memory stats:

let stats = profiler.getMemoryStats()
print(stats.usedMemory)

Or set a custom warning threshold:

profiler.setMemoryWarningThreshold(300 * 1024 * 1024) // 300MB

And yes, it’s safe to use in Swift Packages, doesn’t require UIKit, and respects DEBUG-only environments out of the box.

Final Thoughts

Memory issues in SwiftUI aren’t always obvious - especially with its declarative magic. But they’re real. When you see gradual memory climbs during usage, don’t just blame Instruments for being slow - build tools that work for you.

This profiler helped me stabilize performance, eliminate leaks, and ship confidently.

Try it, fork it, improve it.

Let’s build apps that run lean - not leak.

Let me know what you think in the comments - and if you use this in your app, I’d love to hear your results.
