From 0 to over 1,000 Unit Tests: The DI Framework Behind It
Why I built OrbitCore, an open-source Swift DI container with three retain policies, thread-safe lazy injection, and a test pattern that scaled past 1,000 unit tests.
If you’ve built an iOS app with more than three screens, you’ve felt the pain. You start passing dependencies through initializers, and it works - until your app graph gets deep enough that every view model needs six parameters, half of which exist only to forward them further down.
I’m the developer behind Engramr - Reminders & Alarms, an app built with Clean Architecture across domain, data, and presentation layers. What started as clean init injection gradually turned into a wiring problem that Swift’s type system alone doesn’t solve.
So I built OrbitCore - an open-source Swift Package that handles dependency registration, scoped resolution, thread-safe lazy injection, and test container swapping, with zero external dependencies. iOS 16+, Swift 6.0+.
This article is about why it exists and what problems it solves. For integration steps and code examples, check the GitHub repository.
The Five Problems That Pushed Me to Build This
1. Init Injection Doesn’t Scale
Init injection is the textbook answer. And for two layers deep, it’s fine. But in a real app:
let networkService = NetworkService()
let authService = AuthService(network: networkService)
let userService = UserService(network: networkService, auth: authService)
let loggingService = LoggingService()
let viewModel = UsersViewModel(userService: userService, logging: loggingService)
let view = UsersView(viewModel: viewModel)Now multiply that by 30 screens. Your composition root becomes a 200-line wiring file where every new dependency means touching ten lines. Add a parameter to NetworkService, and half the app’s initialization chain breaks.
You’re not injecting dependencies. You’re manually threading a graph.
2. Singletons Hiding in Plain Sight
Most iOS projects eventually create a ServiceContainer or AppDependencies struct with static properties. It solves the wiring problem but introduces a worse one: every service lives forever.
struct AppDependencies {
static let networkService = NetworkService()
static let userService = UserService()
static let cacheService = CacheService() // Lives forever. Why?
}There’s no lifecycle management. No way to say “this should exist only while someone needs it.” No way to tear down after logout. Everything is a singleton, whether it should be or not.
3. Testing Requires Surgical Replacement
Want to mock UserService in tests? With static singletons, you need conditional compilation flags, protocol witnesses with manual swapping, or a full test target that duplicates your composition root. None of these are good. The first leaks test code into production. The second is fragile. The third doubles your maintenance surface.
4. Lazy Properties Aren’t Thread-Safe
Swift’s lazy var is not thread-safe. If two threads access an uninitialized lazy property simultaneously, you get double initialization - or worse, a crash. In a dependency injection context where services are resolved on first access, this is a real problem, not a theoretical one.
5. No Scoping Means No Memory Strategy
Should your analytics service live forever? Probably. Should a temporary image cache? Probably not. Without explicit scoping, every dependency has the same lifecycle: birth at registration, death at app termination.
You can’t express “keep this alive while someone references it, then release it automatically.” You can’t express “create a fresh instance every time.” You get one behavior - permanent - and hope for the best.
The Journey: From Protocol to Container
The first version was just ContainerProtocol - a protocol with register and resolve. Five lines of interface. It worked for hello-world examples but broke immediately under real conditions:
- Resolving a dependency inside a builder deadlocked the container
- Concurrent access during app launch caused race conditions
- No way to express lifecycle intent beyond “exists” and “doesn’t exist”
The real shift happened when I asked: what if the container understood how long things should live? Not just “registered” or “not registered.” Three explicit policies. You declare your intent, and the container enforces it.
The Core Idea: Three Retain Policies, Zero Ambiguity
Instead of one implicit lifecycle, OrbitCore gives you three explicit ones:
// New instance every time. No caching. No sharing.
container.register(with: .default) { _ in
UserService() as UserServiceProtocol
}
// Singleton. One instance for the container's lifetime.
container.register(with: .strong) { _ in
LoggingService() as LoggingServiceProtocol
}
// Cached while referenced. Auto-released when nobody holds it.
container.register(with: .weak) { _ in
TemporaryImageCache() as ImageCacheProtocol
}.default is for transient objects - view models, controllers, request-scoped services. Every resolve() call runs the builder fresh.
.strong is for true singletons - logging, analytics, network clients. One instance, cached in a dictionary, returned on every resolve.
.weak is the interesting one. It uses NSMapTable with .weakMemory value options. The container caches the instance, but holds it weakly. While your view controller or view model keeps a strong reference, the cache returns the same instance. The moment all external references are released, the entry auto-nils. Next resolve creates a fresh one.
No manual cache invalidation. No reference counting. The runtime handles it.
Thread-Safe Resolution - Without Deadlocks
This was the hardest problem, and the one most DI containers get wrong. Consider this registration:
container.register(with: .strong) { container in
let logger: LoggingServiceProtocol = try container.resolve()
return UserService(logger: logger)
}The builder for UserService calls container.resolve() to get its dependency. If the container uses a simple NSLock, this deadlocks - the lock is already held by the outer resolve() call.
OrbitCore uses NSRecursiveLock. The same thread can acquire it multiple times without deadlocking. Nested resolution chains - no matter how deep - work correctly.
private let lock = NSRecursiveLock()
public func resolve<T>() throws -> T! {
lock.lock()
defer { lock.unlock() }
// Resolution logic - may call resolve() again for dependencies
}Why NSRecursiveLock and not a dispatch queue or actor? Because resolution must be synchronous and re-entrant. Dispatch queues can’t re-enter. Actors require async. A recursive lock is the precise tool for this problem.
@Injected: One Line, Lazy, Thread-Safe
The property wrapper is where most developers interact with OrbitCore:
final class UsersViewModel {
@Injected var userService: UserServiceProtocol
@Injected var loggingService: LoggingServiceProtocol
func fetchUsers() async {
let users = try await userService.fetchUsers()
loggingService.log(event: "users_loaded")
}
}No initializer parameters. No wiring. The container resolves each dependency on first access.
Under the hood, @Injected solves two problems:
Lazy resolution. Dependencies aren’t resolved at init time - they’re resolved on first property access via Swift’s lazy var. This means registration order doesn’t matter, and circular dependencies don’t crash at construction time.
Thread-safe first access. Swift’s lazy var isn’t thread-safe. Two threads hitting an uninitialized @Injected property simultaneously could trigger double resolution. The wrapper guards access with NSLock:
@propertyWrapper public class Injected<T: Sendable> {
private let lock = NSLock()
public var wrappedValue: T {
lock.lock(); defer { lock.unlock() }
return _wrappedValue
}
private lazy var _wrappedValue: T = {
do {
return try container.resolve()
} catch {
fatalError(error.localizedDescription)
}
}()
}Note: NSLock, not NSRecursiveLock. A property wrapper should never recursively access itself. Using the lighter lock is an intentional design choice - it’s faster and makes invalid access patterns crash loudly instead of silently re-entering.
For eager resolution (resolve at init, not first access):
@Injected(lazy: false) var analyticsService: AnalyticsServiceProtocolTesting: Swap the Graph, Not the Code
OrbitCore detects XCTest automatically:
public extension ProcessInfo {
static var isTesting: Bool {
processInfo.environment["XCInjectBundleInto"] != nil
|| processInfo.environment["XCTestConfigurationFilePath"] != nil
|| processInfo.environment["XCTestSessionIdentifier"] != nil
}
}Your app’s entry point uses this to choose the dependency graph:
init() {
let container = Container()
if ProcessInfo.isTesting {
injectTestDependencies(into: container)
} else {
injectAllDependencies(into: container)
}
ContainerHolder.container = container
}No #if DEBUG. No build flags. No conditional compilation. The test target sets an environment variable that XCTest provides automatically. Production builds never see test code.
The TestContainer Pattern
For unit tests, OrbitCore’s protocol-based design enables a lightweight test container:
final class TestContainer: ContainerProtocol {
var dependencies: [Any] = []
init(dependencies: [Any] = []) {
self.dependencies = dependencies
}
func resolve<T>() throws -> T! {
dependencies.first(where: { $0 is T }) as? T
}
// resolveWithType, resolveAll, reset, register: trivial passthroughs over `dependencies`
}No factories. No builders. Just a flat array of pre-built instances. Combined with mock services that track calls via enum:
final class MockUserService: UserServiceProtocol, @unchecked Sendable {
private(set) var calls: [Call] = []
enum Call: Equatable {
case fetchUsers
case fetchUser(identifier: String)
}
var fetchUsersResult: Result<[UserDomainModel], Error> = .success([])
func fetchUsers() async throws -> [UserDomainModel] {
calls.append(.fetchUsers)
return try fetchUsersResult.get()
}
}With those two pieces in place - TestContainer and a mock with a Call enum - you verify behavior, call sequences, and side effects through Equatable assertions. The next section is what makes it scale.
Unit Tests at Scale: The Helpers Behind 1,000+ Tests
The TestContainer above is the foundation. What turns it into a suite that scales is three small helpers and a single design decision about where the seam lives.
Across two years and multiple apps and SDKs built on this pattern, the test count has crossed 1,000+. The reason it kept scaling - instead of buckling under setUp/tearDown overhead - is that adding test #1,001 costs the same as adding test #11.
Three helpers, one seam
Each test owns its own dependency graph. setUp calls createTestDependencies(mockA, mockB) to install a fresh TestContainer. tearDown calls removeTestDependencies() to nil out ContainerHolder.container. insertTestDependencies is the escape hatch for tests that need to layer in an extra mock partway through, without rebuilding the graph.
func createTestDependencies(_ dependencies: Any...) {
ContainerHolder.container = TestContainer(dependencies: dependencies)
}
func removeTestDependencies() {
ContainerHolder.container = nil
}
func insertTestDependencies(_ dependencies: Any...) {
let existingContainer = ContainerHolder.container as? TestContainer
let testContainer: TestContainer = existingContainer ?? .init()
testContainer.dependencies.append(contentsOf: dependencies)
ContainerHolder.container = testContainer
}Because the seam is a single static property - ContainerHolder.container - there’s exactly one thing to swap. No scattered setMockA(...), setMockB(...), setMockC(...) calls. No accidental leakage from one test to the next. Tests can run in parallel and in any order because none of them share state with any other.
A real ViewModel test
This is what a typical test in the suite actually looks like - two mocks, state assertions, and call-sequence verification, all in one readable block:
final class UsersViewModelTests: XCTestCase {
private var mockUserService: MockUserService!
private var mockLoggingService: MockLoggingService!
private var sut: UsersViewModel!
override func setUp() {
super.setUp()
mockUserService = MockUserService()
mockLoggingService = MockLoggingService()
sut = UsersViewModel(
userService: mockUserService,
loggingService: mockLoggingService
)
}
override func tearDown() {
removeTestDependencies()
sut = nil
mockLoggingService = nil
mockUserService = nil
super.tearDown()
}
func testFetchUsersSuccess() async {
let expectedUsers = [
UserDomainModel(identifier: "1", name: "Alice", email: "alice@test.com"),
UserDomainModel(identifier: "2", name: "Bob", email: "bob@test.com")
]
mockUserService.fetchUsersResult = .success(expectedUsers)
await sut.fetchUsers()
XCTAssertEqual(sut.viewState, .loaded(expectedUsers))
XCTAssertEqual(mockUserService.calls, [.fetchUsers])
XCTAssertEqual(mockLoggingService.calls, [
.log(event: "users_screen_load", parameters: [:])
])
}
}This particular SUT uses init injection, so the mocks go straight into the initializer and removeTestDependencies() is just hygiene. When the SUT instead uses @Injected properties, the only change is in setUp: call createTestDependencies(mockUserService, mockLoggingService) so the property wrappers resolve from the test graph. Same pattern, same helpers - the wiring path doesn’t change the test.
Why it scales
Three earlier design choices in OrbitCore are doing the heavy lifting here:
- Protocol-first dependencies - every service is mockable by construction. No wrapping, no test-only subclasses, no
@testableworkarounds beyond what XCTest already gives you. - Flat-array
TestContainer- no factories, no retain policies, no thread-safety plumbing in tests. Type-match lookup is enough because tests don’t need lifecycle semantics. ContainerHolderas a single seam - one swap point per test instead of scattered registrations acrossAppDelegate, view controllers, and child coordinators.
Together, those three add up to the same boilerplate cost for every test in the suite. Adding test #1,001 takes the same time as adding test #11.
Reset: Selective Teardown for Logout Flows
User logs out. You need to clear every cached service - user data, session tokens, cached content - but keep infrastructure services alive: logging, analytics, crash reporting.
container.reset(ignoreDependencies: [
String(reflecting: LoggingServiceProtocol.self),
String(reflecting: AnalyticsServiceProtocol.self)
])reset() clears all cached .strong and .weak instances. The ignoreDependencies parameter takes type keys to preserve. Next resolve() for cleared types runs the builder fresh.
No app restart. No re-initialization of the entire graph. Surgical teardown.
The Architecture: 7 Files, Zero Dependencies
OrbitCore is a Swift Package with strict separation:
Core:
ContainerProtocol- Public interface. 5 methods. Protocol-driven for testability.Container- Default implementation. NSRecursiveLock, factory storage, three-policy resolution.ContainerRetainPolicy- Enum:.default,.strong,.weak.ContainerError- Single error case:.missingFactoryMethod. No overengineering.ContainerHolder- Static singleton access point.nonisolated(unsafe)for Swift 6.
Property Wrappers:
@Injected- Lazy, thread-safe, Sendable-constrained resolution.
Extensions:
ProcessInfo.isTesting- XCTest environment detection.
The package knows nothing about your services. Your app registers its own types. The package just resolves them.
@Injected → ContainerHolder → Container → Factory → Instance
↑ ↓
└── resolve() ──┘ (recursive)Swift 6 Strict Concurrency: Already Compliant
OrbitCore ships with full Swift 6 strict concurrency compliance:
ContainerError: Sendable- errors can cross isolation boundaries@Injected<T: Sendable>- generic constraint ensures resolved types are sendableContainerHolderusesnonisolated(unsafe)- required for static mutable state, with thread-safety managed by the caller- Test mocks use
@unchecked Sendable- appropriate for test-only code
No warnings. No workarounds. No @preconcurrency imports.
Why NSMapTable for Weak Caching
This is worth a section because most Swift developers haven’t used NSMapTable, and the weak caching behavior is the SDK’s most elegant feature.
private var weakInstances = NSMapTable<NSString, AnyObject>(
keyOptions: [.copyIn],
valueOptions: [.weakMemory]
).weakMemory means the map table does not retain its values. When the last strong reference to a cached instance is released, the entry auto-nils. On next resolve(), the container finds nil, runs the builder fresh, and caches the new instance.
This is how you express “shared while needed, released when not” - without manual invalidation, timers, or reference counting. The Objective-C runtime does the bookkeeping for you.
Use case: an image processing pipeline that multiple view models share during a flow. While the flow is active, they share one instance. When the user navigates away and all view models are deallocated, the pipeline releases automatically. Next time someone needs it, a fresh one is created.
String(reflecting:) - The Type Key Nobody Talks About
How does the container know which factory to invoke for resolve<UserService>()?
let key = String(reflecting: T.self)String(reflecting:) produces a fully qualified type name:
String(reflecting: String.self)→"Swift.String"String(reflecting: UserService.self)→"MyApp.UserService"String(reflecting: Array<String>.self)→"Swift.Array<Swift.String>"
It handles generics, nested types, and module namespacing. It’s deterministic and unique per type. No ObjectIdentifier, no custom hashing, no type erasure - just the type’s canonical name as a string.
This also makes reset(ignoreDependencies:) work intuitively: you pass the same String(reflecting:) output to specify which types to preserve.
Honest Downsides
- Runtime resolution, not compile-time. If you forget to register a dependency, you find out at runtime, not compile time. The error is clear (
ContainerError.missingFactoryMethod), but it’s still a runtime failure. - Global state via ContainerHolder. The static container is convenient but is global mutable state. Thread-safety is the caller’s responsibility. Set it once at launch and don’t reassign.
- No circular dependency detection. If Service A’s builder resolves Service B, and Service B’s builder resolves Service A, you get a stack overflow. The recursive lock prevents deadlock but not infinite recursion.
- No scope hierarchies. There’s one container, not nested child containers.
Key Takeaways
Declare lifecycle intent explicitly. Three retain policies eliminate the “everything is a singleton” trap.
.default,.strong,.weak- pick one. Your future self will thank you.
Use NSRecursiveLock for nested resolution. Builders that resolve other dependencies are the common case, not the edge case. A simple lock deadlocks. A recursive lock handles it cleanly.
Lazy properties need their own lock. Swift’s
lazy varis not thread-safe. If your property wrapper resolves lazily, guard first access with NSLock.
Detect tests via environment, not build flags.
ProcessInfo.environment["XCInjectBundleInto"]is set by XCTest automatically. No#if DEBUGneeded.
Track mock calls with enums.
enum Call: Equatablegives you precise, readable assertions on call sequences and parameters. Better than boolean flags or manual counters.
NSMapTable is underrated.
.weakMemoryvalue options give you automatic cache invalidation backed by the Objective-C runtime. Use it for any “shared while needed” pattern.
280 lines is enough. A DI container doesn’t need to be a framework. It needs to register, resolve, scope, and get out of the way.
The SDK is open-source: OrbitCore on GitHub, with a full example iOS app showing the test helpers, mocks, and ViewModel patterns from this article. The full architecture ships in Engramr - Reminders & Alarms, available on the App Store.
